ATTRIBUTES
- Automatic with reverse
- 168cc engine
- 6in ground clearance
SHIPPING
- The shipping that is stated at check out is an estimate. Your actual shipping may be less--call or click here. We also may be able to give you a better price on this vehicle since our costs to purchase are constantly changing.
OPTIONS
- Option 1: 80% Assembled: Comes in a crate delivered by 18 wheeler on a pallet. You complete the assembly and testing of your vehicle.
- Option 2: Fully Assembled and Tested: With this option we deliver to your door fully assembled and tested and ready to ride. Delivered by roll back or pickup truck with trailer.. Call for a quote.
- Option 3: You Pickup. You can pickup your vehicle from one of our warehouses including TX, CA, GA, VA, IN and other locations around the country: Call us and we will remove the shipping fee.
- Windshield: +$250
- Lightbar: +$200
- Winch: +$200
- Bumper: +$100
We are the only seller that carries a full line of replacement parts for vehicles that we sell.
Compare BDX to other sellers:
Ten Reasons Why BDX is the only place to purchase your vehicle - click here
- One FULL Year Warranty parts and labor (nobody else offers this)
- Lifetime phone Tech Support with real technicians (nobody else offers this)
- We specialize in parts and others don't. With others parts may take months.
- You get up to 25% discount on parts for life as a preferred customer.
- We have real hands on repair technicians for tech support
- Straight talk and honest dealings. Know what you are buying. Read why!
- Click here to see more reasons.
Call to check color availability
SPECIFICATIONS
- EPA certified
- Engine type: 4-stroke, single cylinder, air cooled
- Displacement: 168.9cc
- Max HP: 11.1hp/7500 RPM
- Max torque: 11N.m@5000 RPM
- Bore x stroke: 2.4x2.28 inches
- Max speed: 33 mph
- Climbing ability: 20-25 degrees
- Ignition: C.D.I
- Starting system: Electric
- Battery: 12V 10Ah
- Engine oil: SAE 15W-40
- Clutch: Automatic CTV with reverse
- Driveline / Driving wheel: Chain / Dual wheel drive
- Suspension F / R: Independent Dual A-arm / Double Oil Damped Shock
- Brakes, F / R: Both hydraulic brakes, Disc
- Tires, F / R: 22x7-10 / 22x10-10
- Fuel capacity: 2 gal
- Weight, G.W. / N.W.: 840 / 705 lbs
- Max load: 500 lbs
- Dump bed max load: 165 lbs
- Wheelbase: 72 inches
- OA L x W x H: 100x53x63 inches
- Packing size: 91X54X35 inches
- Height to seat: 23.6 inches
- Min ground clearance: 6.3 inches
- Dump bed dimension: 27.5X45.3X9.5
